SUB 9006-AS
Active dual 18-inch subwoofer
Model：SUB 9006-AS
Wholesale Price
Market price
Net Weight
43
kg
Stock surplus
隐藏域元素占位
- Description
-
- Brand: Silver Hyuk
- Commodity name: Active dual 18-inch subwoofer
- Commodity ID: SUB 9006-AS
SUB 9006-AS
Active High-Power Subwoofer
FEATURES
7200 Watt Peak power - 3600 Watt RMS
142 dB max SPL
30 Hz - 400 Hz frequency response
2 x 18" Woofer
DSP controlled Input section with selectable presets
RDNet remote control
Delay control
Baltic birch cabinetThe SUB 9006-AS is one of the most powerful 2x18-inch subwoofers in the live sound industry. It features two high-power, ultra-ventilated 18-inch neodymium magnet woofers with 4.0-inch voice coils, delivering a powerful low-frequency response. Driven by a 7200-watt digital amplifier, the SUB 9006-AS operates stably even in the most demanding environments. Its cabinet design perfectly matches the HDL50-A and HDL10-A array systems, allowing for easy construction of modular subwoofer systems. The amplifier integrates a low-noise 32-bit DSP circuitry, controlled via the proprietary RDNet network, easily handling soft clipping, RMS limiting, polarity, amplitude, timing, and EQ. All settings, monitoring, and advanced functions are available in the RDNet network management software. The rear control panel adjusts input sensitivity, low-cut, crossover, volume, bypass, delay, and preset selection. A regulated power supply ensures ample power delivery within a 100V to 260V voltage range. The 18-inch neodymium magnet woofer is designed to deliver the purest, most powerful, and least distorted low-frequency reproduction. The cone is composed of 30% carbon fiber, 20% glass fiber, and 50% cellulose pulp. This special chemical composition has been carefully developed to enhance the cone's robustness and rigidity, preventing any deformation that could lead to efficiency loss. 4.0-inch inner and outer voice coils are wound around a robust glass fiber skeleton, ensuring more efficient heat dissipation. The skeleton is reinforced both internally and externally with Nomex material, enhancing overall structural rigidity and enabling better energy transfer between the voice coil and the cone body. To dissipate the heat generated by the powerful voice coil, engineers developed a unique ultra-ventilation system with extremely low power compression. The cone is waterproof. Parameter
System Type: Active dual 18-inch subwoofer
Frequency Range： 30 Hz - 400 Hz
Maximum SPL2： 142dB
LF Driver： 2 x 18-inch neodymium magnet drivers, 4.0-inch voice coil
Input signal： bal/unbal
Input connectors： XLR, RDNet Ethercon
Output connectors： XLR, RDNet Ethercon
Input sensitivity： +4 dBu
Hi-Pass Frequencies： 30Hz, 40Hz
Low-Pass Frequencies： Variable from 50Hz to 400Hz
Protections： Thermal, RMS
Limiter： Fast Limiter
Controls： Gain, EQ, Preset, Phase switch, Output Delay Settings
RDNet： Onboard
Total Power： 7200 W Peak, 3600 W RMS
Low frequencies： 7200 W Peak, 3600 W RMS
Cooling： Convection/Forced
Connections： Powercon IN/OUT
Cabinet/Case Material： Baltic birch plywood
Hardware： 2 x M20
Handles： 8 side
Pole mount/Cap： M20 thread
Grille： Steel
Color： Black
working voltage： 110V50Hz - 230V 60Hz
Box material： 18 mm superior splint
Box appearance： Black wear-resistant paint treatment
Size(W x H x D): 1188×558×785mm
Packing Specifications: 1260×630×855mm
Net Weight： 86kg
packing weight: 92Kg
