- Description
-
- Brand: Silver Hyuk
- Commodity name: Active live sound system
- Commodity ID: VTX2615
This combination is designed to be an economical, portable, scalable and efficient active live system that delivers unparalleled sound reinforcement in any venue of any size, anywhere in the world. Ideal for touring sound solutions, small gigs, corporate events, houses of worship or any venue that requires outstanding sound reinforcement when space is limited.
Product Model: VTX206 System Type： Dual 6.5-inch two-way linear array speaker Frequency Range (-3dB): 70Hz-18KHz System Sensitivity: 97 db (1w @ 1m) Maximum SPL: 128db Power Rating: 250 W Continuous, 1000 W Peak Horizontial Coverage: 120° Vertical Coverage: Array dependent LF Driver: Two 6.5-inch bass drivers LF Power Handling： 200 W Continuous, 1200 W Peak HF Driver: 1.75-inch voice coil compression driver HF Power Handling： 75 W Continuous, 300 W Peak Impedance: Passive (+1,-1)8Ω CONNECTORS: (2) Neutrik® Speakon® NL4MP Enclosure: High quality Russian birch wood, CNC manufacturing OPTIONS: Black textured paint or waterproof finish Dimensions: (W x H x D) 576×203×357mm Packing Specifications: 650×280×430mm Net Weight： 14.7 kg packing weight: 16 Kg Product Model: VTX15PD System Type： Active 15-inch array subwoofer Frequency Range (-3dB): 48Hz-180Hz Maximum SPL: 132db Amplifier Type: Class D Bi-Amplification power output： 2×1500W LF Driver: 15-inch JBL 15H49A subwooferr Cooling method： Fan cooling working voltage： 110V 50Hz / 230V 60Hz Enclosure: High quality Russian birch wood, CNC manufacturing OPTIONS: Black textured paint or waterproof finish Dimensions: (W x H x D)576×464×620mm Packing Specifications: 745×540×650mm Net Weight： 37.5 kg packing weight: 39.5 Kg YAMAHA MG10XU 10 channel mixing console Up to 4 microphones / 10 line inputs (4 mono + 3 stereo) 1stereo bus 1 AUX (including FX) D-PRE microphone preamp with inverting transistor circuit. Single knob compressor Advanced effects: SPX, including 24 sets of preset effects 24-bit/192kHz 2-in/2-out USB audio function Works with iPad (version 2 or higher) via Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter Includes Cubase AI DAW download version software PAD switch on mono input channel +48V phantom power XLR balanced output Metal body Appearance dimensions (W×H×D): 244 mm x 71 mm x 294 mm (9.6"x 2.8"x 11.6") Net weight: 2.1 kg (4.63 lbs.) Product Model LV330 Transmitter technical data
RF section Frequency control PLL circuit synthesizer Frequency range 530 ... 580 MHz 620 ... 670 MHz 740.8 ... 790.8 MHz Used bandwidth max. 50MHz Channels 200 Frequency spacing 250 kHz RF power at ANT 20 mW, -3 dB Modulation technique FM Modulation deviation 1 kHz NF ±24 kHz Maximum modulation deviation 1 kHz NF ±48 kHz Audio Audio frequency response (1 kHz) 60 Hz ... 18 kHz; -3dB Distortion at 1 kHz and typical < 0,9% (0,5%) Signal-to-noise ratio S / N ratio ≥ 100 dB Operating voltage 3 V Power at rated voltage ≤ 130mA Standby ≤ 100 µA Battery 1.5V alkaline*2 Use ≥ 8 hours Receiver technical data Frequency range 530-580MHZ 620-670MHZ 740.8-790.8MHZ True diversity Use bandwidth 50MHZ Number of receiving frequency channels 200 Frequency interval 250KHZ 1IF frequency 110MHZ Oscillator frequency 120.7MHZ 2IF frequency 10.7MHZ Modulation technology Wideband FM Modulation frequency deviation 24KHZ 48KHZ maximum value S/N=80 dB < 10 µV (6 µV) S/N max > 110 dB Antenna 2x BNC 50 Ω NF part Output voltage 500mv Distortion at 1 kHz and typical value <1% (0.3 %) NF frequency response 50 Hz - 18 kHz; 3dB Connector 6.35 mm Separate A and B connectors XLR Nominal voltage 14.5V AC Voltage range 13.5V-18V AC Nominal current 650MA
